Vertical Machining Centre VMC 1050 with Siemens 810D Controller

Travel Spindle Rapid Repeatability Make

: : : : :

1050 (mm) X 600 (mm) X 550 (mm) 10000 RPM 25M/Min 3 Micron Position Accuracy : 2 Micron JYOTI CNC AUTOMATION SYSTEMS PVT. LTD., RAJKOT

Vertical Machining Centre TX32 with Syntec Controller

Travel Spindle Rapid Repeatability Make

: : : : :

500 (mm) X 400 (mm) X 400 (mm) 10000 RPM 25M/Min 3 Micron Position Accuracy : 2 Micron DATIAN CNC SYSTEMS PVT. LTD., CHINA

CNC Turning Center Model Dx150 with Siemens Controller 820D Solution Line Controller

Travel Spindle Rapid Repeatability Make

: : : : :

DIA 300 (mm) x 500 (mm) 4000 RPM 25M/Min 5 Micron Position Accuracy : 4 Micron JYOTI CNC AUTOMATION SYSTEMS PVT. LTD., RAJKOT

CNC EDM Model CM 434Z With ZNC

Table Size (WxD) Table Travel (XxY) Ram Travel (Z1) Max. Machining Current Make

: : : : :

650 (mm) × 400 (mm) 400 (mm) × 300 (mm) 350 (mm) 50 AMP Max. Machining Speed : 350 mm 3 / min CHMER, TAIWAN

Facilities Available At Tool Room Sr. No. Description Company Name Qty 1 Surfece Grinding Machine SAMSONS Taiwan Make 1 2 Shaping Machine JIWAN Make 2 3 Lathe Machine ATUL Make 4 4 Vertical Drilling Machine PREMIER Make 5 Our workshop is also equipped with all types of inspection equipments. Software Computer Aided Designing and Manufacturing Softwares I-DEAS 9NX I-DEAS12NX UNIGRAPHICS NX6 DELCAM PowerMILL 2012

Value At Innovative, cost or prices are alien words to us. To keep the business running, we have to pay due attention to financial aspects, but what drives us in real sense is the value that we provide to our clients. Enthusiasm There is a minute yet distinctive difference between doing things and doing them with vigour. Enthusiasm adds all together new dimensions to the tasks, making them easier, paving way for a long term, and truly heartening relations with our clients.

Facilities Available At Tool Room Sr. No. Description Company Name Qty 1 Microprocessor Based Height Gauge Trimos Metrology, 1   0-900 M.M., L.C. 0.1Micron Swiss   2 Digital Height Gauge 0-600m.m. Mahr, Germany 1 Facilities Available At Tool Room Sr. No. Description Company Name Qty 1 Air Gauging System Dial Type With BAKER Make 2   L.C. Of 1 Micron

Other than this our workshop is also equipped with all types of inspection equipments
